UL Fire Fighting Pendent Sprinkler Heads
UL Listed Pendent Fire Sprinkler135°F/(57°C) 155°F/(68°C) 175°F/(79°C) 200°F/(93°C) 286°F/(141°C)Standard Response or Quick ResponseNPT1/2", BSPT1/2"Chrome Finished, Brass Finished, White PaintingBulb Nominal D......
Send Inquiry
Product Description
UL Listed Pendent Fire Sprinkler
135°F/(57°C) 155°F/(68°C) 175°F/(79°C) 200°F/(93°C) 286°F/(141°C)
Standard Response or Quick Response
NPT1/2", BSPT1/2"
Chrome Finished, Brass Finished, White Painting
| Bulb Nominal Dia.& Response | Ø5mm Standard Response |
| Thread Size | NPT1/2" or BSPT1/2" |
| Nominal Orifice Size | 1/2 Inch |
| Nominal K-Factor | 5.6 (U.S.)/80 (metric) |
| Max. Working Pressure | 175psig/1.2MPa (12bar) |
| Sprinkler Finish | Natural Brass, Chrome Finished or White Painting (RAL9010) |
| Nominal Temp. Rating | 135°F/(57°C) 155°F/(68°C) 175°F/(79°C) 200°F/(93°C) 286°F/(141°C) |
| Listing and Approvals | UL Listed |
| Bulb Nominal Dia.& Response | Ø3mm Quick Response |
| Thread Size | NPT1/2" or BSPT1/2" |
| Nominal Orifice Size | 1/2 Inch |
| Nominal K-Factor | 5.6 (U.S.)/80 (metric) |
| Max. Working Pressure | 175psig/1.2MPa (12bar) |
| Sprinkler Finish | Natural Brass, Chrome Finished or White Painting (RAL9010) |
| Nominal Temp. Rating °F (°C) | 135°F/(57°C) 155°F/(68°C) 175°F/(79°C) 200°F/(93°C) 286°F/(141°C) |
| Listing and Approvals | UL Listed |
